ASTM A269 TP 316TI SS Seamless Tubes Suppliers, Stainless Steel 316TI Tubing, Stainless Steel 316TI Cold Drawn Tubes Stockholder, SS 316TI Tubing Exporter In India.
Stainless Steel DIN 1.4571 Seamless Tubes Stockist, SS UNS S31635 Seamless Tubing, SS 316TI Cold Drawn Tubes, SS 316TI Seamless Tubes, SS 316TI Seamless Tubing In India.
Spark Steel is one of the most reliable and trusted stockist and supplier of 316Ti Stainless Steel Tubing, which has a long track record in the steel industry and we focus on building lasting partnerships with our customers. If the material is certified as SS 316 EFW Tubes that implies the carbon is at a maximum level and this can only be certified to the straight grade if the increased mechanicals is met. When stainless steel was first introduced, SS 316L ERW Tubes has been selected for countless applications across a wide array of industries due to its excellent mechanical and corrosion properties. If SS 316Ti Seamless Tubes is certified as a straight grade, the carbon content would have to be at a level of 0.03 % maximum in order to be dual certified. The L grade in SS 316L Welded Tubes has a lower maximum carbon limit and the straight grade has increased mechanical properties. Now, as more and more emphasis is placed on choosing materials that are sustainable, Stainless Steel 316 Round Tubes is also gaining significant recognition due to its outstanding environmental properties. Stainless Steel 316L Square Tubes is 100 % recyclable, is typically able to meet the lifetime requirements for a project, and has an outstanding end of life recapture rates. We have the insight necessary to advise you on the optimal solution of Stainless Steel 316 Rectangular Tubes for your specific application.
ASTM A213 TP316TI Stainless Steel Seamless Tube Manufacturers in India
ASTM A213 TP316TI Stainless Steel Seamless Tube Specification
|
Stainless Steel Pipes
|
||||
|---|---|---|---|---|
|
Material
|
Size
|
Sch.
|
Specification
|
Manufacturer
|
|
ASTM A213 Stainless Steel 316TI Seamless Tube
|
15 NB
To 300 NB |
Sch. 5s
Sch. 10s Sch. 40s Sch. 80s Sch. 160s Sch. XXS |
ASTM A-213
|
Imported
Choksi Remi & Ratnamani |
| Note:- | ||||
|---|---|---|---|---|
| End | Plain End, Beveled End, Threaded | |||
| End Protection | Plastic Caps | |||
| Outside Finish | 2B, No.4, No.1, No.8 Mirror Finish for Stainless Steel Pipes, Finish as per customer Requirements | |||
| Delivery Condition | Annealed and Pickled, Polished, Bright Annealed, Cold Drawn | |||
|
SS Pipe Grades
|
TP 304/ SS 304
TP 304H/ SS304H TP 304L/ SS 304L TP 304LN/ SS 304LN TP 316/ SS316 |
TP 316H/ SS 316H
TP 316L/ SS 316L TP 316LN/ SS 316LN TP 316Ti/ SS 316Ti TP 309/ SS 309 |
TP 310/ SS 310
TP 317L/ SS 317L TP 321/ SS 321 TP 347/ SS 347 TP 409/ SS 409 |
TP 410/ SS 410
TP 420/ SS 420 TP 430/ SS 430 TP 446/ SS 446 TP 202/ SS 202 etc. |
| ASTM A213 TP316TI Stainless Steel Seamless Tubes Specification | ASTM A 269/A 213 / EN 10216-5 / NACE MR0175/PED 97/23 EC | |||
| Outside Diameter: | 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock, OD Size Steel Tubes available Ex-stock | |||
| Thickness Range | 0.3mm – 50 mm, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS | |||
| Type | Seamless / ERW / Welded / Fabricated / CDW Type: SS 316TI Seamless Tube | SS 316TI ERW Tube | SS 316TI Welded Tube | SS 316TI Fabricated Tube | SS 316TI CDW Tubes, SS316TI Hydraulic and Instrumentation Tubes, SS 316TI Coiled Tubing, SS 316TI Capillary Tubes, SS316TI Hydraulic and Instrumentation Tubes, SS 316TI Coiled Tubing, SS 316TI Capillary Tubes |
|||
| Brand/ Origin | European Origin, Japanese Origin, Korea Origin, US Origin, Russia Origin, Indian Origin | |||
| SS 316TI Tube Manufacturer | Posco Korea, VDM Germany, Tubacex, Nippon Steel Corporation, Sumitomo Japan, Indian Mills, Walsin | |||
| Form | SS 316TI Round Pipes/Tubes, SS 316TI Square Pipes/Tubes, SS 316TI Rectangular Pipe/Tubes, SS 316TI Coiled Tubes, SS 316TI “U” Shape, SS 316TI Pan Cake Coils, SS 316TI Hydraulic Tubes | |||
| Special Pipes | Stainless Steel 316TI Fabricated Tube (with radiography) | |||
| In Length of | Single Random, Double Random , Standard & Cut length | |||
| Value Added Service | Draw & Expansion as per required Size & Length Polish (Electro & Commercial) Heat Treatment Bending Annealed & Pickled Sand Blasting Machining Etc. |
|||
| Test Certificate | Manufacturer Test Certificate/
Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection, Mill Test Certificates, EN 10204 3.1, Chemical Reports, Mechanical Reports, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, NABL Approved Lab Reports, Destructive Test Report, Non Destructive Test Reports |
|||
| Specialize | Stainless Steel 316TI Fabricated Pipe Stainless Steel 316TI Square & Rectangle & Other Odd Size SS Pipe Sizes and Specifications other than above can be manufactured on request |
|||
| UNSPSC Code | 40171621 (Industrial welded stainless steel 316L pipe) 40171622 (Industrial seamless stainless steel 316L pipe) |
|||
| Other Pipes & Tubes |
|
|||
Ready stock available:top 10 Manufacturers of ASTM A213 Stainless Steel Seamless Tube under one roof at most attractive price offer
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
-
ASTM A213 TP316TI Stainless Steel Seamless Tube manufacturers in india
Spark steel is one of the oldest Manufacturer, Distributors and Supplier of High Quality ASTM A269 TP 316TI SS Seamless Tubes. We provide a wide range of Stainless Steel TP 316TI Tubes in Seamless, Welded, SAW, LSAW, DSAW etc. Our range comprises of Stainless Steel TP 316TI Seamless Tubes. Available in different dimensions & grades, these Stainless Steel TP 316TI Seamless Tubes are widely used in different industries like Dairy, Food processing, engineering, construction and many more. We also offer competitive range of Stainless Steel TP 316TI Seamless Tubes as per client’s requirement. Spark Steel is Approved Manufacturer & supplier of Stainless Steel TP 316TI Seamless Tubes by GASCO, KNPC, SAUDI ARAMCO, SABIC, ORPIC, NIORDC & PIDMCO.
Stainless Steel 316TI Seamless Tubing Specification
-
ASTM A213 TP316TI Stainless Steel Seamless Tube suppliers in india
Tube Range : 6.35 mm OD To 101.6 mm OD Guage: 25 SWG - 10 SWG
Outer Diameter : 3.00 mm - 219.10 mm
Wall Thickness : 0.40 mm - 12.70 mm
Schedules : 5, 10S, 10, 30, 40S, 40, 80, 80S, XS, 160, XXH
Length : Upto 30 meters, Custom Cut Lengths
Specifications : ASTM A269 / ASTM SA269
Types : Round, Square, Rectangle, Coil, "U" Shape, Hydraulic & Honed Tubes
ASTM A213 TP316TI Stainless Steel Seamless Tube Equivalent Grades
| STANDARD | UNS | WERKSTOFF NR. | JIS | AFNOR | BS | GOST | EN |
|---|---|---|---|---|---|---|---|
| SS 316TI | S31635 | 1.4571 | SUS 316TI | Z6CNDT17‐12 | 320S31 | 08Ch17N13M2T | X6CrNiMoTi17-12-2 |
ASTM A213 TP316TI SS Seamless Tubes suppliers in India, Stainless Steel 316TI Tubes Manufacturers in India, Stainless Steel 316TI Cold Drawn Tubes Dealers, SS 316TI Tubes Distributors In India, Stainless Steel 316TI Seamless Tube manufacturers in India, A213 TP316TI, SS 316TI Seamless Tube
| Stainless Steel 304 Seamless Tubes | Stainless Steel 304L Seamless Tubes |
| Stainless Steel 304H Seamless Tubes | Stainless Steel 310S Seamless Tubes |
| Stainless Steel 310 Seamless Tubes | Stainless Steel 310H Seamless Tubes |
| Stainless Steel 316 Seamless Tubes | Stainless Steel 316L Seamless Tubes |
| Stainless Steel 316H Seamless Tubes | Stainless Steel 316Ti Seamless Tubes |
| Stainless Steel 317 Seamless Tubes | Stainless Steel 317L Seamless Tubes |
| Stainless Steel 321 Seamless Tubes | Stainless Steel 321H Seamless Tubes |
| Stainless Steel 347 Seamless Tubes | Stainless Steel 347H Seamless Tubes |
| Stainless Steel 904L Seamless Tubes |
316Ti Stainless Steel Tubing Tube Chemical Composition
| SS | 316TI |
|---|---|
| Ni | 10 - 14 |
| N | 0.10 max |
| Cr | 16 – 18 |
| C | 0.08 max |
| Si | 0.75 max |
| Mn | 2 max |
| P | 0.045 max |
| S | 0.030 max |
| Mo | 2.00 - 3.00 |
316Ti Stainless Steel Tubing Mechanical Properties
| Grade | 316TI |
|---|---|
| Tensile Strength (MPa) min | 515 |
| Yield Strength 0.2% Proof (MPa) min | 205 |
| Elongation (% in 50mm) min | 35 |
| Hardness | |
| Rockwell B (HR B) max | 75 |
| Brinell (HB) max | 205 |
316Ti SS Tubing Physical properties
| Specific Heat (0-100°C) | Thermal Conductivity | Thermal Expansion | Modulus Elasticity | Electrical Resistivity | Density |
|---|---|---|---|---|---|
| 500 | 14.6 | 16.5 | 193 | 7.4 | 7.99 |
| J.kg-1.°K-1 | W.m -1.°K-1 | mm/m/°C | GPa | μohm/cm | g/cm3 |
ASTM A213 TP316TI Stainless Steel Seamless Tube size & stock range
| Tube/ Tube Type | NB Sizes | Sch 5 | Sch 10 | Sch 40 | Sch 80 | Sch 160 |
|---|---|---|---|---|---|---|
| 316Ti Stainless Steel Tube | 1/2 |
 |
|
|
|
|
| 316Ti Stainless Steel Tube | 3/4 |
|
|
|
|
|
| 316Ti Stainless Steel Tubing | 1 |
|
|
|
|
|
| 316Ti SS Tube | 1.25 |
|
|
|
|
|
| 316Ti SS Tubes | 1.5 |
|
|
|
|
|
| 316Ti SS Tubing | 2 |
|
|
|
|
|
| 316Ti Stainless Steel Tubes | 2.5 |
|
|
|
|
|
| 316Ti Stainless Steel Tube | 3 |
|
|
|
|
|
| 316Ti Stainless Steel Tubing | 3.5 |
|
|
|
|
|
| 316Ti Stainless Steel Tube | 4 |
|
|
|
|
|
| 316Ti SS Tubes | 5 |
|
|
|
|
|
| 316Ti SS Tubing | 6 |
|
|
|
|
|
| 316Ti SS Tube | 8 |
|
|
|
|
|
| 316Ti Stainless Steel Tubes | 10 |
|
|
|
|
|
| 316Ti Stainless Steel Tube | 12 |
|
|
|
|
|
| 316Ti Stainless Steel Tubing | 14 |
|
|
|
|
|
| 316Ti Stainless Steel Tube | 16 |
|
|
|
|
|
| 316Ti SSl Tubes | 18 |
|
|
|
|
|
| 316Ti SSl Tubing | 20 |
|
|
|
|
|
| 316Ti SS Tube | 22 |
|
|
|
|
|
| 316Ti Stainless Steel Tubes | 24 |
|
|
|
|
Types Of Stainless Steel TP 316TI Seamless Tubing
-
316TI Stainless Steel Seamless Tubing Exporters in india
-
- Stainless Steel 316TI Seamless Tubes
- SS TP 316TI Seamless Tubes
- Stainless Steel 316TI Tubes
- SS 316TI Tubes
- Stainless Steel 316TI Cold Drawn Tubes
- ASTM A 269 316TI Stainless Steel Seamless Tubes
-
- SS TP 316TI Cold Drawn Tubes
- AISI SS TP 316TI Tubing
- Stainless Steel 316TI Tubing
- SS UNS S31635 Seamless Tubing
- Stainless Steel 316TI Seamless Tubing
- DIN 1.4571 Stainless Steel 316TI Seamless Tubes
| ASTM A213 TP316TI Stainless Steel Seamless Tube | ||
|---|---|---|
|
|
|
ASTM A213 TP316TI Stainless Steel Seamless Tube Price List
- ASTM A213 TP 316TI tube seamless & welded
US $1-10 / Kilogram (FOB Price) - TP 316TI stainless steel seamless tube
US $4.0-7.5 / Kilogram (FOB Price) - TP 316TI hot finished seamless stainless steel tube Suppliers
US $720-1500 / Ton (FOB Price) - TP 316TI stainless seamless steel tube
US $3000-5000 / Ton (FOB Price) - SA213 TP316TI Seamless Tube
US $1.5-9 / Kilogram (FOB Price) - astm a213 TP316TI seamless tube
US $4500-5000 / Ton (FOB Price) - ASTM A268 TP316TI Stainless seamless Steel tubes
US $3.8-5 / Kilogram (FOB Price) - TP 316TI seamless stainless steel tube
US $500-1000 / Ton (FOB Price) - TP316TI stainless seamless steel tube
US $3000-5000 / Ton (FOB Price) - Grade 316TI ASTM A213 Stainless Steel Seamless Tube
US $400-1300 / Ton (FOB Price) - ASTM A213 Seamless Tube TP 316TI
US $300-1110 / Ton (FOB Price) - High Quality Stainless Steel 316TI Seamless tubes
US $1200-1000 / Ton (FOB Price) - Fabricated Stainless Steel tubes A213 GR TP 316TI
US $1300-12000 / Ton (FOB Price) - Different Sizes of 316TI Stainless Steel Seamless tubes
US $3.3-5 / Kilogram (FOB Price) - SS 316TI tubes
US $700-1316TI / Metric Ton (FOB Price) - AISI 316TI SS Seamless Round Tube manufacturer
US $800-1300 / Metric Ton (FOB Price) - A213 / SA 213 316TI stainless steel tubes
US $1600-1200 / Ton (FOB Price) - ASTM A213 TP 316TI SS Rectangular Tube
US $60-120 / Kilogram (FOB Price) - SS 316TI Cold Drawn Seamless Tube
US $1000-2000 / Metric Ton (FOB Price) - 316TI High Precision Stainless Steel Tube
US $1200-10500 / Ton (FOB Price) - 316TI SUS Steel Seamless Tube
US $530-1100 / Ton (FOB Price)
| ASTM A213 TP316TI Stainless Steel Seamless Tube Outside Diameter & Tolerance |
|---|
| Nominal Pipe Size (inches) |
Outside Diameter |
Schedule | ||||||||
| 5S | 10S | 40S | 80S | |||||||
| (mm) | (inches) | Wall Thickness and Weight | ||||||||
| mm (in) |
kg/m | mm (in) |
kg/m | mm (in) |
kg/m | mm (in) |
kg/m | |||
| 1/8 | 10.3 | 0.405 | - | - | 1.25 (0.049) |
0.28 | 1.73 (0.068) |
0.37 | 2.42 (0.095) |
0.47 |
| 1/4 | 13.7 | 0.540 | - | - | 1.66 (0.065) |
0.49 | 2.24 (0.088) |
0.63 | 3.03 (0.119) |
0.80 |
| 3/8 | 17.2 | 0.675 | - | - | 1.66 (0.065) |
0.63 | 2.32 (0.091) |
0.85 | 3.20 (0.126) |
1.10 |
| 1/2 | 21.3 | 0.840 | 1.65 (0.065) |
0.81 | 2.11 (0.083) |
1.00 | 2.77 (0.109) |
1.27 | 3.74 (0.147) |
1.62 |
| 3/4 | 26.7 | 1.050 | 1.65 (0.065) |
1.02 | 2.11 (0.083) |
1.28 | 2.87 (0.113) |
1.68 | 3.92 (0.154) |
2.20 |
| 1 | 33.4 | 1.315 | 1.65 (0.065) |
1.30 | 2.77 (0.109) |
2.09 | 3.38 (0.133) |
2.50 | 4.55 (0.179) |
3.24 |
| 1 1/4 | 42.2 | 1.660 | 1.65 (0.065) |
1.66 | 2.77 (0.109) |
2.69 | 3.56 (0.140) |
3.39 | 4.86 (0.191) |
4.47 |
| 1 1/2 | 48.3 | 1.900 | 1.65 (0.065) |
1.91 | 2.77 (0.109) |
3.11 | 3.69 (0.145) |
4.06 | 5.08 (0.200) |
5.41 |
| 2 | 60.3 | 2.375 | 1.65 (0.065) |
2.40 | 2.77 (0.109) |
3.93 | 3.92 (0.154) |
5.45 | 5.54 (0.218) |
7.49 |
| 2 1/2 | 73.0 | 2.875 | 2.11 (0.083) |
3.69 | 3.05 (0.120) |
5.26 | 5.16 (0.203) |
8.64 | 7.01 (0.276) |
11.4 |
| 3 | 88.9 | 3.500 | 2.11 (0.083) |
4.52 | 3.05 (0.120) |
6.46 | 5.49 (0.216) |
11.3 | 7.62 (0.300) |
15.3 |
| 3 1/2 | 101.6 | 4.000 | 2.11 (0.083) |
5.18 | 3.05 (0.120) |
7.41 | 5.74 (0.226) |
13.6 | 8.08 (0.318) |
18.6 |
| 4 | 114.3 | 4.500 | 2.11 (0.083) |
5.84 | 3.05 (0.120) |
8.37 | 6.02 (0.237) |
16.1 | 8.56 (0.337) |
22.3 |
| 5 | 141.3 | 5.563 | 2.77 (0.109) |
9.46 | 3.41 (0.134) |
11.6 | 6.56 (0.258) |
21.8 | 9.53 (0.375) |
31.0 |
| 6 | 168.3 | 6.625 | 2.77 (0.109) |
11.3 | 3.41 (0.134) |
13.9 | 7.12 (0.280) |
28.3 | 10.98 (0.432) |
42.6 |
| 8 | 219.1 | 8.625 | 2.77 (0.109) |
14.8 | 3.76 (0.148) |
20.0 | 8.18 (0.322) |
42.5 | 12.70 (0.500) |
64.6 |
| 10 | 273.1 | 10.750 | 3.41 (0.134) |
22.7 | 4.20 (0.165) |
27.8 | 9.28 (0.365) |
60.4 | 12.70 (0.500) |
81.5 |
| 12 | 323.9 | 12.750 | 3.97 (0.156) |
31.3 | 4.58 (0.180) |
36.1 | 9.53 (0.375) |
73.9 | 12.70 (0.500) |
97.4 |
|
Stainless Steel 316TI tubing Value Added Options
|
|
|---|---|
Stainless Steel 316TI tube Polishing |
ASTM A312 TP 316TI Stainless Steel Seamless tube as per #4 Polish, #6 Polish, #7 Polish or a #8 mirror finish. Stainless steel polished pipes can also be cut to size. |
Stainless Steel 316TI tube Beveling |
Bevel ASTM A312 TP 316TI Stainless Steel Seamless tube to prepare for welding or other processes. |
| Stainless Steel 316TI tube Honing/Turning | Hone pipe and tube, using a precision abrasion process in order to obtain a desired finish or close dimensional tolerance. |
Heatreating & Annealing |
Some grades of stainless steel pipe and tube can be heatreated to change the mechanical properties. Precipitation Hardening Stainless Steels such as 17-4PH can be heatreated. 410 stainless steel plate can also be heatreated. In some cases, secondary annealing 300 series stainless steel may be required depending on the application |
Positive Material Identification (PMI) |
PMI testing in house for most stainless steel grades, or we can work with independent labs to complete PMI in order to meet customer specifications. |
SS 316TI Tube UT Testing |
In some cases, UT testing of the stainless steel tube and tueb may be required. We can assist you with this requirement. |
ASTM A213 TP316TI Stainless Steel Seamless Tube Value Added Services
- Draw & Expansion as per required Size & Length
- Polish (Electro & Commercial) Heat Treatment
- Bending
- Annealed & Pickled
- Sand Blasting
- Machining Etc.
ASTM A213 TP316TI Stainless Steel Seamless Tube Advantages
- High strength
- Resistant to high mechanical stresses
- Resistant to high pressure
- Resistant to high temperature
- Good formability
- Reusable
316Ti Stainless Steel Tubing Marking of packages
-
ASTM A269 TP316TI SS Seamless Tubes Packing
-
ASTM A269 TP316TI SS Seamless Tubes Packing
